ENGINE TYPE |
1-cylinder,
air cooled, 4-stroke |
|
CYLINDER
TYPE |
SINGLE |
|
DISPLACEMENT |
147ML |
|
COMPRESSION
RATIO |
9.2:1 |
|
Maximum Speed |
52.79mile/h |
|
Clutch Model |
Hand Operation |
|
Shift Gears Model |
1-N-2-3-4-5 |
|
BORE
x STROKE (MM) |
56.5x49.5mm |
|
MAX
POWER (KW/RPM) |
8.6kw(8500r/min) |
|
IGNITION |
C.D.I |
|
LUBRICATION |
pressure&
splash |
|
|
12v-3AH |
|
FEUL
TANK CAPACITY (L) |
8L |
|
ENGINE
OIL CAPACITY (L) |
0.85L |
|
TRANSMISSION |
5
speed |
|
TRANSMISSION
TYPE |
chain |
|
REVERSE
GEAR (Y/N) |
NO |
|
STARTING |
electric
start / kick start |
|
CHASSIS |
|
|
F/R
TIRE SIZE AND AIR PRESURE |
Front: 3.00-12-4PR
Rear: 2.50-14-4PR |
|
F/R
BRAKE |
disc/disc |
|
BRAKE
OPERATION MODE |
front:
hand/ rear: foot |
|
FRONT
SUSPENSION |
hydraulic
pressure & spring |
|
REAR
SUSPENSION |
hydraulic
pressure & spring |
|
DIMENSIONS |
|
|
OVERALL
SIZE(MM) |
1880
x 775 x 1020mm |
|
SEAT
HEIGHT |
775mm |
|
WHEEL
BASE (MM) |
1275mm |
|
GROUND
CLEARANCE (MM) |
245 |
|
Gross Weight |
281.6 lbs. |
|
Net Weight |
222.2 lbs. |
